9600 Mobile Computer
Select Length
Negative Barcode
Plessey
Convert to UK Plessey
Transmit Check Digit
Telepen
Original Telepen
(Numeric)
AIM Telepen (Full
ASCII)
GS1 DataBar-14 (RSS-14)
GS1 DataBar-14 is short for GS1 DataBar Omnidirectional. This group consists of (1) GS1 DataBar
Omnidirectional, (2) GS1 DataBar Truncated, (3) GS1 DataBar Stacked, and (4) GS1 DataBar
Stacked Omnidirectional.
Transmit Code ID
Transmit Application
ID
Transmit Check Digit
GS1 DataBar Limited (RSS Limited)
Transmit Code ID
Transmit Application
ID
Transmit Check Digit
GS1 DataBar Expanded (RSS Expanded)
This group consists of (1) GS1 DataBar Expanded, and (2) GS1 DataBar Expanded Stacked.
Transmit Code ID
EAN-8
Convert to EAN-13
Transmit Check Digit
Addon 2 / Addon 5
EAN-13 / UPC-A
ISBN Conversion
ISSN Conversion
168
Reference Manual
One or two fixed lengths
Range
When applied, each occurrence of the character "A" in the
barcode data will be replaced by the character "X".
Decide whether to include the two check digits in the data
being transmitted.
The original Telepen includes numeric characters.
AIM Telepen (Full ASCII) includes all the alphanumeric and
special characters.
Decide whether to include Code ID ("]e0") will be included
in the data being transmitted.
Decide whether to include the Application ID ("01") in the
data being transmitted.
Decide whether to include the check digit in the data being
transmitted.
Refer to RSS-14.
Refer to RSS-14.
Refer to RSS-14.
Refer to RSS-14.
The EAN-8 barcode will be expanded into EAN-13, and the
next processing will follow the settings configured for
EAN-13.
Decide whether to include the check digit in the data being
transmitted.
Decide whether to decode EAN-8 with addons.
The EAN-13 barcode starting with 978 and 979 will be
converted to ISBN.
The EAN-13 barcode starting with 977 will be converted to
ISSN.
4~127
Disable
Disable
No
Yes
Disable
Yes
No
Disable
Yes
Yes
Yes
Disable
Yes
Yes
Yes
Disable
Yes
Enable
No
Yes
No
Enable
No
No
