7.3 RFID READER SETTINGS

If the RFID scan engine is present, configurable options will be displayed.
Note: Because it is possible to read barcode and RFID tag at the same time, it is
recommended that only one scan engine is enabled at a time to prevent from
misreading.
Some RFID tags support both read/write operations, on a page-by-page basis. You may
find it necessary to define your own read/write operation. For reference only, the table
below lists the start page for read/write operation on a number of RFID tags.
Start Page Tag Type
-1 Start from byte 0 of the default page (see below) for all tags
4 Mifare
4 SR176
3 ICODE SLI
0 LRI512
3 SRF55VxxP
0 EM4135
0 Tag-it HF-I
0 Others
5 ICODE
0 Tag-it
Note: Please refer to the specifications of your RFID tags for memory organization.
130
Reference Manual
Standard
ISO 14443A
ISO 14443B
ISO 15693
ISO 15693
ISO 15693
ISO 15693
ISO 15693
ISO 15693
ICODE® (Phillips)
Tag-it® (TI)
