9600 Mobile Computer

1.6 DATA CAPTURE

1.6.1 BARCODE & RFID READER
A wide variety of scan engines is available for delivering flexibility to meet different
requirements. Depending on the scan engine integrated, the mobile computer is capable
of scanning barcodes of a number of symbologies that are enabled by default while
running ReaderConfig.exe. If you need to scan barcodes that are encoded in a different
symbology, enable the symbology first. Refer to Appendixes for details on scan engine
settings.
Appendix I - Scan Engine Settings
Appendix II - Linear Imager (CCD), Laser (SE950)
settings as well as symbology settings for the CCD or Laser scan engine.
Appendix III - 2D Imager
symbology settings for the 2D scan engine.
Note: The mobile computer allows the co-existence of one integrated scan engine and
the RFID reader.

1.6.2 DIGITAL CAMERA

An integrated 2 mega-pixel CMOS camera in the mobile computer is specifically designed
for collecting image data. We provide an image capture utility that is specifically designed
to turn on the camera and capture image.
30
Reference Manual
lists the symbologies and RFID tags supported.
provides information on the reader settings as well as
provides information on the reader
