CipherLab 9600 Reference Manual page 72

This is the control of networking over USB cable. It is enabled automatically when
the mobile computer is connected to PC via USB cable.
This is the control of Ethernet module AX88772. It is enabled automatically when
the mobile computer is seated in the Ethernet Cradle.
Refer to
This is the control of 802.11b/g module for wireless local area networking (WLAN)
connection, which is not available until the power to 802.11b/g module is turned
on through Power Management
This is the control of BT module for wireless personal area networking (WPAN)
connection, which is not available until the power to BT module is turned on
through Power Management
Note: By default, DHCP is enabled for networking. Instead of using DHCP, select
[Properties] and specify a static IP address to the mobile computer. Only change
these settings according to your network administrator's instructions.
Toolbar Items Description
Tap this button to open the Connection menu. The
available options depend on the connection you
select.
Tap this button to toggle on/off the connection you
select. The toggle is used for Enable/Disable or
Connect/Disconnect.
Tap this button to delete the connection you select.
Tap this button to view the properties of the
connection you select.
When available, the connection status icon
When connected, this icon will become
When disconnected, this icon will become
6.2 GPRS Connection.
When available, the connection status icon
When connected, this icon will become
When disconnected, this icon will become
When available, the connection status icon
When connected, this icon will become
When disconnected, this icon will become
Chapter 3 Configuring 9600 Mobile Computer
will appear on the taskbar.
.
again.
.
will appear on the taskbar.
.
again.
.
will appear on the taskbar.
.
again.
Remarks
Tap and hold the icon of a
desired
Then, select an option from
its associated menu.
connection type.
59
