Understanding the printer menus
Use
Portrait Width
3–8.5 inches
76–216 mm
Portrait Height
3–14.17 inches
76–360 mm
Feed Direction
Short Edge
Long Edge
Reports menu
Reports menu
Use
Menu Settings Page
Device Statistics
Network Setup Page
Profiles List
To
Set the portrait width.
Notes:
•
If the width exceeds the maximum, then the printer uses the
maximum width allowed.
•
8.5 inches is the US factory default setting. You can increase the
width in 0.01‑inch increments.
•
216 mm is the international factory default setting. You can increase
the width in 1‑mm increments.
Set the portrait height.
Notes:
•
If the height exceeds the maximum, then the printer uses the
maximum height allowed.
•
14 inches is the US factory default setting. You can increase the
height in 0.01‑inch increments.
•
356 mm is the international factory default setting. You can increase
the height in 1‑mm increments.
Specify the feed direction if the paper can be loaded in either direction.
Notes:
•
Short Edge is the factory default setting.
•
Long Edge appears only when the longest edge is shorter than the
maximum width supported in the tray.
To
Print a report containing information about the paper loaded in trays, installed
memory, total page count, alarms, timeouts, printer control panel language,
TCP/IP address, status of supplies, status of the network connection, and other
information.
Print a report containing printer statistics, such as supply information and details
about printed pages.
Print a report containing information about the network printer settings, such as
the TCP/IP address information.
Note: This menu item appears only in network printers or in printers connected
to print servers.
Print a list of profiles stored in the printer.
Note: This menu item appears only when LDSS is enabled.
58
