Erbauer ERB2502SE User Manual page 9

254mm (10”) compound mitre saw
Table of Contents

Advertisement

13
12
11
Fig 1
1.
UPPER BLADE GUARD
2.
SWITCH HANDLE
3.
LOWER BLADE GUARD
4.
STOP BLOCK
5.
RIGHT EXTENSION WING
6.
MITRE SCALE
7.
POSITIVE STOP LOCKING LEVER
8.
MITRE HANDLE
9.
MOUNTING HOLE
10. BASE
11. LEFT EXTENSION WING
12. HOLD-DOWN CLAMP
13. DUST BAG
14. COVER PLATE
9
254MM (10") COMPOUND MITRE SAW
254MM (10") COMPOUND MITRE SAW
1
14
10
2
3
4
6
9
8
5
7
9
