1
171 mm
Fig 25
2
3
Fig 26
254MM (10") COMPOUND MITRE SAW 254MM (10") COMPOUND MITRE SAW
1
No-Hands Zone
171 mm
1
Starting a cut:
● Place hands at least 171 mm away from the
path of the blade – out of the "no-hands zone"
(1). (See fig. 25)
● Clamp workpiece firmly against the fence to
prevent movement toward the blade.
● With the power switch OFF, bring the saw
blade down to the workpiece to see the cutting
path of the blade.
● Squeeze trigger switch to start saw.
● Lower blade into workpiece with a firm
downward motion.
Finishing a cut:
● Hold the cutting arm in the down position.
● Release trigger switch and wait for all
moving parts to stop before moving your
hands and raising the cutting arm.
● If the blade doesn't stop within 6 seconds,
unplug the saw and follow the instructions in
TROUBLESHOOTING GUIDE section.
Before releasing jammed material:
● Release trigger switch.
● Wait for all moving parts to stop before
moving your hands and raising cutting arm.
● Unplug the mitre saw.

4. Basic saw operations

Warning: For your convenience, your
saw has a blade brake. The brake is not
a safety device. Never rely on it to replace
the proper use of the guard on your saw. If
the blade doesn't stop within approximately 6
seconds, wait for the blade to stop, unplug the
saw and contact customer service.
5. To turn saw on
Push down the lock lever (3) and squeeze the
trigger switch (1) to turn the mitre saw ON.
Release the trigger switch to turn the saw
OFF. (See fig. 26)
Note: Make the ON/OFF switch childproof.
Insert a padlock, or chain with padlock,
through the holes (2) in the trigger switch,
locking the tool's switch, preventing children
and other unauthorised users from turning the
machine on.
