Note: The chart below references a compound
cut for crown moulding ONLY WHEN THE
ANGLE BETWEEN THE WALLS EQUALS
EXACTLY 90°.
BEVEL
KEY
SETTING SETTING
33.9° 31.6°
IL
Right
33.9° 31.6°
IR
Left
OL 33.9° 31.6°
Left
OR 33.9° 31.6°
Right
254MM (10") COMPOUND MITRE SAW 254MM (10") COMPOUND MITRE SAW
MITRE
TYPE OF CUT
Inside corner-Left side
1. Position top of moulding against fence.
2. Mitre table set at RIGHT 31.6°.
3. LEFT side is finished piece.
Inside corner-Right side
1. Position bottom of moulding against fence.
2. Mitre table set at LEFT 31.6°.
3. LEFT side is finished piece.
Outside corner-Left side
1. Position bottom of moulding against fence.
2. Mitre table set at LEFT 31.6°.
3. RIGHT side is finished piece.
Outside corner-Right side
1. Position top of moulding against fence.
2. Mitre table set at RIGHT 31.6°.
3. RIGHT side is finished piece.
