  • Page 1 WARRANTY WARRANTY YEARS YEARS ERB2151SE ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 2 ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 3 This guarantee does not affect your statutory rights. This guarantee is only valid in the UK. For further technical advice and spare parts, Please contact the customer helpline number on 01709 876611 quoting your Erbauer model number. ERBAUER 216MM (8”) SLIDING MITRE SAW...

  • Page 4: Safety Instructions

    A spanner or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations. ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 5 You should: - Work in a well-ventilated area. - Work with approved safety equipment, such as those dust masks that are specially designed to fi lter microscopic particles. ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 6 11. Save these instructions. Refer to them frequently and use them to instruct others who may use this tool. If someone borrows this tool, make sure they have these instructions also. ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 7 Caution: Do not let familiarity with your mitre saw makes you careless. Remember that a careless fraction of a second is suffi cient to cause severe injury. ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 8 Remove the mains plug from socket before carrying out any adjustment or servicing. SYMBOLS SYMBOLS Read the manual Warning Wear gloves Wear dust mask, eye & ear protection Conforms to relevant safety standards ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 9 LASER GUIDE LASER GUIDE 9. 9. BASE BASE 10. TURNTABLE TURNTABLE 11. LEFT EXTENSION TABLE LEFT EXTENSION TABLE 12. FENCE FENCE 13. HOLD-DOWN CLAMP HOLD-DOWN CLAMP 14. SLIDE CARRIAGE LOCK KNOB SLIDE CARRIAGE LOCK KNOB ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 10 MOTOR 20. POSITIVE STOP LOCKING LEVER POSITIVE STOP LOCKING LEVER 21. LOWER BLADE GUARD LOCK LEVER LOWER BLADE GUARD LOCK LEVER 22. LASER ON/OFF SWITCH LASER ON/OFF SWITCH 23. BLADE BLADE SPANNER STORAGE STORAGE ERBAUER 216MM (8”) SLIDING MITRE SAW...

  • Page 11: Technical Data

    Sound pressure level: 96.4 dB (A) Sound power level: 109 dB (A) Vibration level: 6.75 m/s ACCESSORIES ACCESSORIES Blade Spanner 1 pc Dust Bag 1 pc Hold-Down Clamp 1 pc Mitre Handle 1 pc ERBAUER 216MM (8”) SLIDING MITRE SAW...

  • Page 12: Assembly Instructions

    2) Push the stop latch knob (3) into the locking hole. IMPORTANT To avoid damage, never carry the mitre saw by the switch handle, the cutting arm or the mitre handle. ALWAYS use the designated carrying handle. ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 13 3) Check for blade clearance by moving the slide carriage through the full motion of the blade in the table slot (See fi g. 9). Note: Replacement table inserts available from 01709 876611. Fig 9 ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 14 Removing blade 1) Unplug the saw from the outlet. 2) The slide carriage should be locked in position by Fig 12 tightening the slide carriage lock knob (1) (See fi g. 12). ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 15 When arbour lock engages, continue to press it in while 11 10 tightening the arbour bolt securely (See fi g. 15). Note: Do not press arbour lock (8) when blade is Fig 16 moving. ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 16 Warning: AVOID DIRECT EYE CONTACT Laser radiated when laser guide is turned on. Avoid direct eye contact. Always unplug the mitre saw from power source before making any adjustments. ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 17 1/2 turn at a time. 3) Once alignment of the laser is achieved, tighten only 1/2 turn at a time the four set screws (5) (See fi g. 22). Fig 22 ERBAUER 216MM (8”) SLIDING MITRE SAW...

  • Page 18: Adjustment Instructions

    ) bevel and recheck for alignment. 5) Repeat steps 1 through 4 if further adjustment is needed. 6) Tighten bevel lock handle (1) and locknut (4) when alignment is achieved (See fi g. 23). Fig 23 ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 19 4) If the mitre angle desired is not one of the nine positive stops, simply lock the mitre table into position by turning the mitre handle in the clockwise direction (See fi g. 26). ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 20 3) Recheck the blade depth by moving the cutting head front to back through the full motion of a cut along the control arm. If the blade touches the inside of the control arm, readjust the setting (See fi g. 28). ERBAUER 216MM (8”) SLIDING MITRE SAW...

  • Page 21: Operation Instructions

    ● Clamp workpiece fi rmly against the fence to prevent movement toward the blade. ● With the power switch OFF, bring the saw blade down to the workpiece to see the cutting path of the blade (See fi g. 29). ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 22 Note: Make the ON/OFF switch childproof. Insert a padlock, or chain with padlock, through the holes in the trigger switch, locking the tool’s switch, preventing children and other unqualifi ed users from turning the machine on. Fig 30 ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 23 (1) to lock the cutting head in position. Positive stops are provided at 0°, 33.9° and 45° (See fi g. 33). Note: When cutting at 45 degrees, ensure guard does not catch on work or base plate. ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 24 7) Slowly move the switch handle toward the fence, completing the cut. 8) Release the trigger and allow the blade to stop spinning before allowing the cutting head to raise (See fi g. 35). ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 25 19.05 mm thick by 63.5 mm high by 457.2 mm long. Attach the wood fence securely and make a full depth cut to make a blade slot. blade slot Fig 38 ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 26 fl at on the saw table. When setting the bevel and mitre angles for compound mitres, remember that the settings are interdependent – changing one changes the other, as well (See fi g. 41, 42). ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 27 3) RIGHT side is fi nished piece. Outside corner-Right side 33.9° 31.6° Right 1) Position top of molding against fence. 2) Mitre table set at RIGHT 31.6°. 3) RIGHT side is fi nished piece. ERBAUER 216MM (8”) SLIDING MITRE SAW...

  • Page 28: Maintenance

    Note: To reinstall the same brushes, fi rst make sure the brushes go back in the way they came out. This will avoid a break- in period that reduces motor performance and increases wear. Replacement Parts available from 01709 876611. ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 29 ERBAUER 216MM (8”) SLIDING MITRE SAW...

  • Page 30: Environmental Protection

    fi tted. A 13AMP (BS1363 or BS1363/A) plug must be used and a 5 AMP fuse must be fi tted. 5 AMP FUSE BLUE N (NEUTRAL) BROWN L (LIVE) OUTER SLEEVE CABLE GRIP ERBAUER 216MM (8”) SLIDING MITRE SAW...
  • Page 31 Erbauer (UK) Ltd. BA22 8RT Declare that the product ERB2151SE ERBAUER 216MM (8”) SLIDING MITRE SAW Complies with the essential health and safety requirements of the following directives: 89/336/EEC – EMC Directive. 2006/95/EC – Low Voltage Directive 98/37/EC – Machinery Directive.
  • Page 32 ERBAUER 216MM (8”) SLIDING MITRE SAW...
