ENVIRONMENTAL PROTECTION

Waste electrical products should not be
disposed of with household waste.
Please recycle where facilities exist.
Check with your Local Authority or
retailer for recycling advice.

PLUG REPLACEMENT

The fuse in the main plug of your power tool
should always be replaced with one of
identical rating.
Check the voltage given on your power tool
matches the supply voltage.
The power tool is supplied with a fitted plug,
however if you should need to fit a new plug
follows the instruction below.
IMPORTANT
The wire in the mains lead are coloured in
accordance with the following code:
Blue ---Neutral
Brown ---Live
The wire that is coloured blue must be
connected to the terminal that is marked with
the letter N. The wire that is coloured brown
must be connected to the terminal that is
marked with the letter L. A 13AMP (BS1363
or BS1363/A) plug must be used and a 5 AMP
fuse must be fitted.
A 13AMP (BS1363 or BS1363/A) plug must be
used and a 5 AMP fuse must be fitted.
BLUE
N (NEUTRAL)
OUTER
SLEEVE
33
254MM (10") COMPOUND MITRE SAW 254MM (10") COMPOUND MITRE SAW
5 AMP
FUSE
BROWN
L (LIVE)
CABLE GRIP
