Erbauer ERB110SSW Manual

70w scroll saw
Hide thumbs

Advertisement

Table of Contents

WARRANTY
YEARS
ERB110SSW
70W SCROLL SAW

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERB110SSW and is the answer not in the manual?

Questions and answers

Related Manuals for Erbauer ERB110SSW

Summary of Contents for Erbauer ERB110SSW

  • Page 1 WARRANTY YEARS ERB110SSW 70W SCROLL SAW...
  • Page 3 Congratulations on your purchase of a quality power tool from Erbauer (UK) Ltd. This product should give you reliable service but for your peace of mind this power tool does carries a 24-month guarantee, the terms of which are detailed below.

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS Warning! When using electric tool, the following basic safety precautions should always be taken to reduce the risk of fire, electric shock and personal injury. Read all these instructions before attempting to operate the product and save these instructions for future reference.
  • Page 5 15. Disconnect tools. When not in use, before servicing and when changing accessories such as blades, bits and cutters, disconnect tools from the power supply. 16. Remove adjusting keys and wrenches. From the habit of checking to see that keys and adjusting wrenches are removed from the tool before turning it on.

  • Page 6: General Description

    5. Caution! Plugs and fuses The Scroll Saw uses a standard amp fuse. A suitable 13-amp outlet socket should be located near the machine in accordance with electrical regulations. 6. Extension leads or reels The Scroll Saw is fitted with a suitable electric power cable which we strongly recom- mend you do not extend or use an extension lead.
  • Page 7 ing thrown in to the eyes, which can result in severe eye damage. Always wear safety goggles before commencing power tool operation. Warning: Always wear safety goggles or face shield. Install blade with teeth pointing down towards the table. Keep fingers a safe distance from the blade. Never leave the scroll saw work area with the power on.
  • Page 8 Warning: identify safety measures to protect the operator that are based on an estimation of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time).Note The use of other tools will reduce the users’...
  • Page 9 1.Adjustable light 2.Blade guard 3.Top blade holder 4.Workpiece press plate 5.Dust blower tube 6.Blade 7.Table insert 8.Blade speed regulator 9.On/Off switch 10.Dust extraction outlet 11.Table tilt lock knob 12.Angle adjustment scale 13.Flexible shaft 14.Saw table 15.Blade tension knob 16.Hose 70W SCROLL SAW...

  • Page 10: Technical Data

    TECHNICAL DATA Volts 230-240 V ~ 50 Hz Rated power 70 W Rated no load speed 550-1600 /min Max. cutting capacity 52 mm 30 mm Depth of throat 406 mm Table bevel 0-45 Blade length 130 mm Flexible shaft length 1100 mm Flexible shaft speed 1650~4800 /min...
  • Page 11 DISCRIPTION PICTURE SPECIFICATION DIAMETER Sanding band 12.5X13 Spherical diamond cutter Spherical diamond cutter 3.9x6.6 Diamond cutter taper 4.3x8.5 Twist drill bit 3.2x27 Twist drill bit 2.3x24 Collet chrome plated 2.3-2.4 Grinding wheel 9.8x10 Grinding wheel 20x3 Grinding wheel 10X3.4 Grinding wheel 5.4X15 Steel wire brush 22x2.5...
  • Page 12 Rubber wheel 12.5x13.3 Brush axial 3.5x10(PVC) Mandrel for felt wheel 4X7.5 Mandrel for cut off wheel 4.5X17 Large felt wheel 25.5x6 Small felt wheel 13x7 Cut off wheel fibre glass 32x1.2 Dressing stone SI carbide 9.8x9.8x25 Cut off wheel grit 120 24x0.6 Cut off wheel grit 280 20.2x0.4...

  • Page 13: Operating Instructions

    OPERATING INSTRUCTIONS NOTE: Before using the tool, read the in- struction book carefully. Before using the tool, please ensure the follow- a) All covers and safety devices have been prop- erly fitted before the machine is switched on. b) It must be possible for the blade to run freely. c) Workpieces do not contain screws, nails or oth- er components that can come into contact with the metal blade.
  • Page 14 Note: Do not over-tighten the screws. Leave enough scope for the foam rubber mat to devel- op a good absorbing effect. 2. Mounting the saw blade guard (see Fig.B1—Fig.B3) Slide the saw blade guard (2) onto the retention bolt (e). Insert the screw through the bore hole of the retention bolt (e) and the saw blade guard (2).
  • Page 15 3. Changing the blade (see Fig.C1 & Fig.C2) Remove the table insert. Turn the blade tension knob (15) anticlockwise to remove the tension from the saw blade (6). Take the blade out of the top blade holder (3), pressing down the upper pendulum arm as you do so.Then take the blade out of the bottom blade holder.

  • Page 16: Operation

    OPERATION Note: 1)Your saw does not cut wood automatically.You have to guide the wood against the blade for op- eration. 2) When cutting thick timber or hardwood, be particularly careful not to bend or twist the blade. This will help to prolong blade life. Fig.E 3) Do not assemble the flexible shaft when saw- ing, otherwise the shaft will damage the spring.
  • Page 17 4. Adapter for saw blades a) Attaching the blade adaptors to plain end blades Adjust one setscrew on each adaptor until it cov- ers approximately half the hole. (Fig.F1) Loosen the other setscrew just enough to slide one adaptor onto each end of the blade (6) as shown.
  • Page 18 5. Using the dust blower tube (see Fig.G) Align the dust blower tube (5) towards the saw blade to blow sawdust away from the sawblade cutting line. 6. Installing the flexible drive shaft (see Fig. H1—Fig.H4) Disconnect from mains supply and ensure ma- chine is switched off.

  • Page 19: Maintenance

    MAINTENANCE Remove the plug from the socket before carrying out any adjustment, servicing or maintenance. 1. Cleaning There are no user serviceable parts in your pow- er tool. Never use water or chemical cleaners to Fig.H4 clean your power tool.Wipe clean with a dry cloth. Always store your power tool in a dry place.
  • Page 20 PROBLEM CAUSE SOLUTION Motor will not run. 1. Problem with power -Check the plug fuse. cord or outlet. Check power at mains supply 2. Motor defective. socket. -Do not attempt any repair. -Have it repaired by a quali- fied service technician. Blades breaking.

  • Page 21: Plug Replacement

    PLUG REPLACEMENT The fuse in the main plug of your power tool should always be replaced with one of identical rating. Check the voltage given on your power tool matches the supply voltage. The power tool is supplied with a fitted plug, however if you should need to fit a new plug follows the instruction below.

  • Page 22: Declaration Of Conformity

    Declaration of Conformity We, Importer Erbauer (UK) Ltd BA22 8RT Declare that the product 70W SCROLL SAW ERB110SSW Complies with the essential health and safety requirements of the following directive: Machinery Directive 98/37/EC Low Voltage Directive 2006/95/EC Electromagnetic Compatibility Directive 2004/108/EC Restrictions of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment 2002/95/EC Standards and technical specifications referred to:...
  • Page 23 70W SCROLL SAW...
