Matrix SETU VFX88L Quick Start Manual page 4

Thank you for choosing Matrix SETU VFX88L!
This Quick Start is meant to help you to install your SETU VFX88L and do
basic configurations to enable you to make and receive VoIP calls using it as
easily as a normal telephone call. For detailed information on installing and
configuring SETU VFX88L, please refer 'Matrix SETU VFX88L System
Manual' on CD-ROM provided to you with the product.
Know your SETU VFX88L
SETU VFX88L has 1 Ethernet port, 8 FXS ports, 1 Lifeline port, a Power
Socket and 10 LEDs.
Figure 1: Back Side Panel
ETHERNET
Ethernet
Switch
Router
Computer
Figure 2: Front Side Panel
FXS1 FXS2 FXS3 FXS4
RJ11
FXS5 FXS6 FXS7 FXS8
PWR F1 F2 F3 F4
STS
F5 F6 F7 F8
LIFELINE
12VDC 2A(Max)
FXO
