PS/2 Female Connector and Pinout
MP-11x

Figure 2-5: RJ-45 Ethernet Connector Pinout

RJ-45 Connector and Pinout
1 2 3 4 5 6 7 8

Figure 2-6: RJ-11 Phone Connector Pinout

RJ-11 Connector and Pinout
1 2 3 4

Figure 2-7: PS/2 Pinout

(TD)
2
(GND) - Ground for Voltage
3
(RD) - Receive Data
6
12
1 - Tx+
4, 5, 7, 8
2 - Tx-
not
3 - Rx+
connected
6 - Rx-
1 - Not connected
2 - Tip
3 -
Ring
4 - Not connected
- Transmit Data
