Abbreviation Meaning
(Sub) Menu
Parameter
EVEntS Submenu for events
recording parameters
HArM Submenu for
harmonics parameters
HArM.F Fundamental frequency See HArM
HiVolt LiMit Upper trigger threshold The threshold value for overvoltage (HiVolt LiMit) while monitoring the TRMS voltage value can be
H_triG Upper trigger threshold See EVEntS
H_triG Upper trigger threshold See StorE
HYSt Hysteresis
I.rAnGE Current range of the
harmonics
LoVolt LiMit Lower trigger threshold The threshold value for undervoltage (LoVolt LiMit) while monitoring the TRMS voltage value can
L_triG Lower trigger threshold See EVEntS
GMC-I Messtechnik GmbH
General Description
Description Specifically for this Instrument
An event is recorded whenever at least one measured value has fallen short of the L-trig threshold
for at least one second, and subsequently at least one measured value has exceeded the H-trig
threshold for at least one second.
Parameters: L-TriG, H-TriG and rAtE DC
Parameters menu for harmonic analysis:
Included parameters: HArM.F (fundamental frequency), U.rAnGE (voltage measuring range) and
I.rAnGE (current measuring range).
Line frequency of the fundamental frequency (here: 16.7, 50, 60 or 400 Hz)
entered here in digits. The full measuring range corresponds to 60,000 digits.
The hysteresis setting allows for efficient use of memory space. During memory mode operation,
new measured data are only saved to a new memory block if they deviate from the previously
stored value by an amount which exceeds the selected hysteresis value.
See HArM
Current range of the harmonics (here: auto, 600 μA, 6, 60, 600 mA, 6 A, 10 A)
Note: Clamp factor is not taken into consideration!
be entered here in digits. The full measuring range corresponds to 60,000 digits.
Glossary
Application Switch
Chapter / Page Position /
Menu
Events recording V
page 28 SEt menu >
EVEntS >
triG
Harmonic analysis
section 5.1.5 SEt menu >
HArM
Power disturbance PQ
analysis SEt menu >
section 5.1.3 MainS
Events recording V
page 28 SEt menu >
EVEntS >
triG
Selective memory All
mode operation StorE menu
section 4.5 > triG
Memory mode All
operation SEt menu >
section 4.5 StorE
Harmonic analysis A
section 5.1.5 SEt menu >
HArM
Power disturbance PQ
analysis SEt menu >
section 5.1.3 MainS
Events recording V
page 28 SEt menu >
EVEntS >
triG
