Maintenance and Calibration

!
Attention!
Disconnect the instrument from the measuring circuit before
opening the battery compartment lid or fuse cover in order
to replace batteries or fuses!
9.1 Displays – Error Messages
Message Function
FUSE
Current measurement
In all operating modes
0 L
Measuring
u r Measuring

9.2 Batteries

Note
Removing the Batteries During Periods of Non-Use
The integrated quartz movement draws power from the bat-
teries even when the instrument is switched off. It's advis-
able to remove the batteries during long periods of non-use
for this reason (e.g. vacation). This prevents excessive
depletion of the batteries, which may result in damage under
unfavorable conditions.
GMC-I Messtechnik GmbH
Meaning
Blown fuse
Battery voltage has fallen below 1.8 V
Indicates overflow (overload)
Indicates that the measuring range has been
fallen short of (under range)
Note
Battery Replacement
Stored measurement data are not lost when the batteries
are replaced. The selected operating parameters remain in
memory, although date and time must be reentered.
Charge Level
The current battery charge level can be queried in the "1nfo" menu:
MEASURE FUNC
1nFo bAtt: 2.75 V.
SETUP ENTER
Make sure that no battery leakage has occurred before initial start-
up, as well as after long periods of storage. Continue to inspect the
batteries for leakage at short, regular intervals.
If battery leakage has occurred, carefully and completely clean the
electrolyte from the instrument with a damp cloth, and replace the
battery before using the instrument.
If the " " symbol appears at the display, the batteries should be
replaced as soon as possible. You can continue working with the
instrument, but reduced measuring accuracy may result.
The instrument requires two 1.5 V batteries in accordance with
IEC R 6 or IEC LR 6, or two equivalent rechargeable NiMH batte-
ries.
Maintenance – Calibration
