• STUN: Program STUN parameters if SETU VGFX is located behind the
NAT router.
Server Address: Enter STUN server address in this field.
• Maximum Length = 40 characters
• All ASCII characters allowed
Default = Blank
Server Port: Enter STUN Server's listening port in this field.
• Valid range = From 1024 to 65535
Default = 3478
Use SIP Port fetched using STUN? This parameter is applicable only when
'Source Port IP Address' is set to 'Use IP Address fetched using STUN'.
• Valid options = Yes/No
Default = No
• Listening Port
SIP Listening Port: SIP Listening port defines the port on which SETU
VGFX listens for SIP messages.
• Valid range = From 1024 to 65535
Default = 5060
RTP Listening Port: RTP Listening port defines the port on which SETU
VGFX listens for RTP packets.
• Valid range = From 1024 to 65526
Default = 8000
SETU VGFX will reboot as soon as you submit the page after changing any
of the Network Port parameters and you will logout of the Web JEEVES.
• If SETU VGFX is connected directly to the Computer for configuring the
system then remove the Ethernet Cable from the Computer and connect it
to the Broadband Modem switch.
• To know IP Address of your SETU VGFX, follow the steps given below:
• Enter programming mode by dialing #19-1234 (Default SE Password)
through FXS Port.
• Dial 21-#* and go On-Hook during confirmation tone.
• VGFX will display its IP Address as CLI on FXS Port.
• Note down the IP Address and exit programming mode.
• Access Web JEEVES using the displayed IP Address through one of
the Computers connected to the LAN Switch or through Internet ready
access Computer (if IP Address of VGFX is Public IP).
