RED i.e. will display the Off-Hook Event.
You can also program Port LEDs for showing the status of SIP Trunks. For
example, if you are using only two mobile ports and other two mobile ports are
disabled then you can program these LEDs for showing the status of SIP Trunks.
(Refer Step 13: 'Checking the Status' for more details)
If LED is programmed for SIP Trunk, it will display following error/event/status:
Event/State/Status
SIP Disable
SIP Registered
SIP Registration
Failed
SIP Authentication
Failed
When all LEDs are programmed for SIP Trunks then no LED indication would
be displayed for FXS/FXO and Mobile Port.
Accessing Web Jeeves:
Programming of SETU VGFX can be done using Web JEEVES only. It does not
support programming of VGFX using telephone instrument except few Network
Port Parameters. To access Web JEEVES, Network Port Parameters should be
programmed first using conventional phone. Follow the steps shown below:
Accessing web jeeves is a very important step in programming VGFX. To access
web jeeves, Network Port Parameters should be programmed first using
conventional phone.
1. Pick up handset of analog phone connected to SETU VGFX.
2. Dial the programming access code #19 followed by default password 1234.
You will get programming tone.
3. To access Web JEEVES using computer/computers in LAN to which VGFX
is connected, change IP address and Subnet Mask of SETU VGFX to bring
VGFX and computer/computers in LAN in the same subnet. Ensure that
their IP Addresses are different.
4. To program Network Port IP address, use command: 11-IP Address-#*
Where,
IP address is of 12 digits in XXX.XXX.XXX.XXX format. Each octet is of
three digits ranging from 001 to 255. For example, to program IP address
192.168.1.120, enter the command 11-192168001120-#*. By default, IP
Address of VGFX is 192.168.001.176.
Cadence (1 cadence is of 5000msec)
Color
ON
-
Green
Red
Red 200
OFF ON
OFF
Continuous
Continuous
200 200
OFF
3400
