Jumpers
The mainboard provides jumpers for setting some mainboard functions. This
section will explain how to change the settings of the mainboard functions using
the jumpers.
Clear CMOS Connector: CLEAR_CMOS
The onboard CMOS RAM stores system configuration data and has an onboard
battery power supply. To reset the CMOS settings, set the jumper on pins 1 and 2
while the system is off. Return the jumper to pins 2 and 3 afterwards. Setting the
jumper while the system is on will damage the mainboard.
Setting
Normal Operation
Clear CMOS setting
Caution:
Except when clearing the RTC RAM, never remove the cap on CLEAR_CMOS
jumper default position. Removing the cap will cause system boot failure.
Avoid clearing the CMOS while the system is on; it will damage the
mainboard.
Voltage Selector for COM2/3/4: J3/2/1
This VCC selector is to determine the input voltage of each COM connector.
Setting
1
2
+5V
ON
ON
+12V
OFF
ON
1
2
3
ON
ON
OFF
OFF
ON
ON
3
OFF
ON
