VB7007 User Manual
Back Panel I/O Ports
•
One VGA port
•
One COM port
•
One parallel port
•
Two RJ-45 LAN ports
•
Four USB 2.0 ports
•
Three audio jacks: Line-in, Line-out, and MIC-in
•
Two PS/2 ports: mouse and keyboard
Onboard I/O Connectors
•
Three COM pin headers (with 5V/12V select)
•
One digital I/O pin header (GPI x 4, GPO x 4)
•
Two USB 2.0 pin headers (up to four additional ports)
•
Two SATA connectors
•
One SMBus pin header
•
One S/PDIF-out connector
•
One dual-channel LVDS panel connector (18/24-bit)
•
One LVDS panel power selector (5V/3.3V)
•
One LVDS inverter pin header
•
One LVDS inverter power selector (5V/12V)
•
One FIR pin header
•
One chassis front panel pin header
•
One front audio pin header
•
Two fan connectors (CPU and SYS)
•
One ATX power connector
