VB7007 User Manual
Digital I/O Connector: DIO
General purpose digital input and output.
Pin
Signal
1
+5V
3
GPO1
5
GPO7
7
GPO26
9
GPO27
11
GND
Pin
Signal
2
+12V
4
GPI4
6
GPI13
8
GPI14
10
GPI15
12
GND
