VB7007 User Manual

SuperIO Device

Onboard Serial Port 1/2/3/4
Set the base I/O port address and IRQ for the onboard serial port A / serial port B.
Selecting Auto allows BIOS to automatically determine the correct base I/O port
address. Settings:
Port
1 Disabled
2 Disabled
3 Disabled
4 Disabled

Onboard Parallel Port

This specifies the I/O port address and IRQ of the onboard parallel port.
Settings: [Disabled, 378/IRQ7, 278/IRQ5, 3BC/IRQ7]
3F8/IRQ4 2F8/IRQ3
3F8/IRQ4 2F8/IRQ3
3F8/IRQ5 2F8/IRQ10
3F8/IRQ5 2F8/IRQ10
Settings
3E8/IRQ4
3E8/IRQ4
3E8/IRQ5
3E8/IRQ5
2E8/IRQ3 Auto
2E8/IRQ3 Auto
2E8/IRQ10 ---
2E8/IRQ10 ---
50
