Swift Motorhome Owners Service Manual page 169

T HET FO RD CAS SETTE TOI L ET
Cassette toilet fault finding
Fault
Bowl does
not drain
when toilet is
flushed.
Cassette is
overfilled
Odours
Soiled bowl
after flushing
No power to
add water to
toilet bowl
Cassette
cannot be
removed
Valve blade
mechanism
sticks or is
hard to open
Major unit
malfunction
168
Remedy
DO NOT REMOVE CASSETTE. While inside the motorhome turn flush knob
anti-clockwise to open valve blade and leave it in the open position. Open
access door on side of motorhome. Rotate pour-out spout outward. Place
appropriate size container under spout cap. Remove cap carefully. Allow bowl
contents to drain into container. This will lower the water level in the bowl.
Replace cap and return pour-out spout to stored position. DO NOT REMOVE
CASSETTE. Go inside the motorhome and turn the flush knob clockwise to
close valve blade. Now, the cassette may be removed following the normal
removal and emptying procedure.
Use proper amount of holding tank deodorant specified on bottle.
Partially fill bowl to cover soiled portion of bowl. Next flush will dissolve waste.
Tip: Leave valve blade open during use.
Check cassette safety sensor switch and fuse-holder for proper engagement
and operation.
Note: Cassette has to be removed to reach switch and fuse.
Insert cassette and try adding water to toilet bowl.
Toilet can be flushed manually. Add water. Add water to bowl from a separate
container. Turn flush knob anti-clockwise to open valve blade. Turn clockwise
to close valve blade.
Check for obstacles under retaining clip. Depress retaining clip several times
to check operation. Remove cassette. Flush knob and valve blade in partial
open position. Close valve blade by moving knob clockwise.
CAUTION: If valve blade is open during cassette removal, severe
damage to system can occur. Never force insertion or removal of the
cassette tank.
Spray light film of silicone on blade.
Contact your original Motorhome Dealer.
