U-MATCH AIR CONDITIONERS

4.2 Indoor Unit

4.2.1 Duct Type
IDI-09, IDI-12, IDI-18 Disassembly procedure
Disassembly of External Casing of Group
Remark: Make sure the power supply is cut off before removal and protect all the parts during disassembly, especially the
screws that should be collected together, in case of missing them.
Step
1. Disassembly of
filter screen for
back return air
2. Disassembly of
side panel for back
return air
3. Disassembly of
cover
plate
for
return air
4. Disassembly of
cover plate
Illustration
MAINTENANCE
Handling Instruction
Pull two filter screens for back
return air
As shown in the
graph, the arrow represents
filter screens for back return
air
· Disassemble
the
fastening
screws for back return air and
take away the back return air
side panel
as shown in the
graph
Disassemble
the
fastening
screws for return air cover
plates and take away the return
air cover plate As shown in the
graph, the arrow represents
cover plates for return air
Disassemble
the
fastening
screws for cover plate and take
away the cover plate As shown
in
the
graph,
the
arrow
represents cover plates
141
