U-MATCH AIR CONDITIONERS
Continued
2
Models
Outdoor unit
Cooling
Nominal
Capacity
Heating
Cooling
Power
Input
Heating
EER/COP
Indoor Unit
Power Supply
Heat Exchange
Type
Drive
Fan
Motor Output
Air Flow
Sound Pressure Level H/M/L
Air Filter
Drain Piping
Indoor Unit Dimensions
(Outline/Package) (H×W×D)
Panel Dimensions
(Outline/Package) (H×W×D)
Weight Net/Gross
Outdoor Unit
Power Supply
Heat Exchange
Type
Fan Motor Output
Fan Motor Speed(H/M/L)
Type
Compressor
Motor Output
Type
Refrigerant Control
Charge
Dimensions (W×H×D)
(Outline/Package)
Weight Net/Gross
Liquid
Gas
Piping
Connections
Max. Length
Max. Height Difference
Indoor unit
kW
Btu/h
kW
Btu/h
kW
kW
W/W
kW
3
m /h
dB(A)
mm
mm
mm
kg
kW
rpm
kW
kg
mm
kg
mm
mm
m
m
ICI-45
ULT-45
12
42000
14
48000
4.8
5.0
2.5/2.8
ICI-45
220-240V~/1 Ph/50HZ
Cross Fin Coil
Centrifugal fan
Direct Driver
0.06
1650
53/ 51 /48
Standard washable synthetic
32×3
840×320×840/
960×394×960
60×950×950/
115×1040×1025
38/46
ULT-45
380-415V~/3 Ph/50HZ
Cross Fin Coil
Axial fan
0.092×2
940/840/700
SCROLL
4.75
R410A
Capillary Tube
3.55
950×1250×412/
1110 × 1385 ×450
112/123
12.7
19.05
50
30
