CONTENT IMPORT ANT SAFETY INFORMATION-------------------------------------------------------------------1 HINTS FOR ECONOMICAL OPERATION-----------------------------------------------------------------2 PAR TS NAMES-------------------------------------------------------------------------------------------------2 MANUAL OPERATION----------------------------------------------------------------------------------------3 ADJUSTING AIR FLOW DIRECTION-------------------------------------------------------------------------4 MAINTENANCE------------------------------------------------------------------------------------------------5 AIR CONDITIONER OPERATIONS AND PERFORMANCE-----------------------------------------------7 INSTALLATION------------------------------------------------------------------------------------------------8 TROUBLES AND CAUSES------------------------------------------------------------------------------------9 TROUBLES AND CAUSES(CONCERNING REMOTE CONTROLLER)----------------------------------9...
IMPORTANT SAFETY INFORMATION CAUTION Danger Do not attempt to install this unit by yourself. This unit requires installation by qualified persons. DANGER Do not attempt to service the unit yourself. This unit has no user serviceable components. Opening or removing the cover will expose you to dangerous voltage.
HINTS FOR ECONOMICAL OPERATION The following should be noticed to ensure an economical operation. (Refer to corresponding chapter for details) Adjust the air flow direction properly to avoid winding toward your body. Adjust the room temperature properly to get a comfortable situation and to avoid supercooling and superheat.
NAMES AND FUNCTIONS a) indoor unit b) outdoor unit c) remote controller d) air-in e) air-out f ) air outlet g) air ow louver (at air outlet) h) connecting pipe i ) drain hose j ) air inlet (with air lter in it) k) drain pump (drain water from indoor unit) l ) infrared signal receiver m) temporary button...
ADJUSTING AIR FLOW DIRECTION Cassette Type While the unit is in operation, you can adjust the air ow louver to change the ow direction and natu- ralize the room temperature evenly. Thus you can enjoy it more comfortably. 1. Set the desired air ow direction. Push the SWING button to adjust the louver to the desired position and push this button again to maintain the louver at this position.
MAINTENANCE WA RNING WARNING Before you clean the air conditioner, be sure to disconnect the power supply plug. Clean ing th e indo or un it and remo te con troller CAUTIONS Use a dry cloth to wipe the indoor unit and remote controller. A cloth dampened with cold water may be used on the indoor unit if it is very dirty.
Cassette Type 1. Open the air-in grill Push the grill switches towards the middle simultaneously as indicated in sketch A. Then pull down the air-in grill. Cautions: The control box cables ,which are originally connected with the main body electrical terminators must be pulled o before doing as indicated above.
AIR C ONDITIONE R OPE R ATIONS AND PE R FOR MANC E Three-minute protection feature A protection feature prevents the air conditioner from being activated for approximately 3 minutes when it restarts immediately after operation. Power failure Power failure during operation will stop the unit completely. The OPERATION lamp on the indoor unit will start ashing when power is restored.
INSTALLATION Location: During cooling operation, the air conditioner will dry the room air, so please x a pipe to drain all the water away from the air conditioner. Please let the indoor unit more than one metre away from the TV set and the radio in order to avoid the picture and noise interference.
TROUBLES AND CAUSES Before you ask for servicing or repairs, check the following points. Recheck Inoperative The power fuse is blown or the circuit breaker has been tripped. The batteries in the remote controller are exhausted. The timer is set. Does not cool or heat well.
Page 13
The Transmission Indicator " " Never Comes On Symptoms Reason and Disposal Causes Check whether the batteries The remote control signal is The remote control signal is in the remote controller are not transmitted, because the not transmitted even when exhausted.
Page 14
The following displays indicate an error or problem: timer lamp running lamp (flashes per second) Display (nixie tube) Malfunction Indoor EEPROM error Communication malfunction between indoor and outdoor units Indoor fan speed malfunction Indoor room temperature sensor open circuit or short circuit Evaporator coil temperature sensor open circuit or short circuit Refrigerant leakage detection...
Page 15
Activate your warranty..Connect to the following link http://www.inventoraiconditioner.com /warranty-inventor simple steps! Select the product type (airconditioner or appliance) for which the warranty will be activated Choose the warranty that corresponds to your product purchase Fill in the required information...
Page 16
ΠΕΡΙΕΧΟΜΕΝΑ Ση αντικέ πληροφορίε ασφάλεια .....................1 Συ βουλέ για οικονο ική χρήση......................2 Ονο ατολογία εξαρτη άτων........................2 Χειροκίνητη λειτουργία..........................3 Προσαρ ογή τη κατεύθυνση του αέρα....................4 Συντήρηση...............................5 Λειτουργίε του κλι ατιστικού και επιδόσει ..................7 Εγκατάσταση..............................8 Προβλή ατα και αιτίε ..........................9 Προβλή ατα και αιτίε (για το τηλεχειριστήριο)................9...
Page 17
ΣΗΜΑΝΤΙΚΕΣ ΠΛΗΡΟΦΟΡΙΕΣ ΑΣΦΑΛΕΙΑΣ ΠΡΟΣΟΧΗ κίνδυνο Μην επιχειρήσετε να το εγκαταστήσετε όνοι σα . Η ονάδα απαιτεί εγκατάσταση από εξειδικευ ένο τεχνικό. ΚΙΝ ΥΝΟΣ Μην επιχειρήσετε επισκευέ στην ονάδα όνοι σα . Η ονάδα δεν διαθέτει τ η ατα που πορουν να επισκευαστούν απο την χρήστη. Το...
Συ βουλέ για οικονο ική χρήση Πρέπει να λάβετε υπόψη τα ακόλουθα για να διασφαλιστεί η οικονο ική λειτουργία. (Ανατρέξτε στα αντίστοιχα κεφάλαια για λεπτο έριε ). • Ρυθμίστε την κατεύθυνση του αέρα σωστά ώστε να μην έρχεται απευθείας πάνω σας. •...
Page 20
ΠΡΟΣΑΡΜΟΓΗ ΚΑΤΕΥΘΥΝΣΗΣ ΑΕΡΑ Μονάδα τύπου κασέτα Όταν η ονάδα είναι σε λειτουργία, πορείτε να ρυθ ίσετε τι περσίδε για να αλλάξετε την ροή του αέρα και να διαχέεται στον χώρο ο οιό ορφα. Επο ένω πορείτε να απολαύσετε τον κλι ατισ ό στον...
ΣΥΝΤΗΡΗΣΗ ΠΡΟΕΙ ΟΠΟΙΗΣΗ Πρίν καθαρίσετε το κλι ατιστικό, βεβαιωθείτε οτι το έχετε αποσυνδέσει από τη πρίζα. Καθαρισ ό τη εσωτερική ονάδα και του τηλεχειριστηρίου. ΠΡΟΣΟΧΗ Χρησι οποιήστε ένα στεγνό ύφασ α για να σκουπίσετε το κλι ατιστικό και το τηλεχειριστήριο. Μπορείτε...
Page 22
Μονάδα τύπου κασέτα 1. Ανοίξτε την γρίλια εισαγωγή αέρα Πιέστε του διακόπτε προ το κέντρο ταυτόχρονα όπω αναγράφεται στο σχή α Α Έπειτα τραβήξτε προ τα κάτω. Προσοχή: Τα καλώδια του κουτιού ελέγχου, τα οποία είναι συνδεδε ένα ε τα κύρια ηλεκτρικά τερ ατικά, πρέπει...
Page 23
Λειτουργίε και απόδοση του κλι ατιστικού Λειτουργία προστασία 3 λεπτών. Είναι ια λειτουργία προστασία η οποία αποτρέπει το κλι ατιστικό από το να επανενεργοποιηθεί για περίπου 3 λεπτά ετά την απενεργοποιησή του. Απώλεια ενέργεια Μια απώλεια ενέργεια κατά την λειτουργία, θα στα ατήσει εντελώ την λειτουργία τη ονάδα...
ΕΓΚΑΤΑΣΤΑΣΗ Τοποθεσία: • Κατά την λειτουργία ψύξης, το κλιματιστικό ξηραίνει τον αέρα του χώρου, επομένως φροντίστε για τη σωστή τοποθέτηση του αρωγού αποστράγγισης για να απομακρύνεται το νερό από τη μονάδα. • Παρακαλείσθε να κρατήσετε απόσταση τουλάχιστον ενός μέτρου μεταξύ της μονάδας και της τηλεόρασηςκαι...
Page 25
ΠΡΟΒΗΜΑΤΑ ΚΑΙ ΑΙΤΙΕΣ Πριν επικοινωνήσετε ε τ ή α επισκευών, ελέγξτε τα ακόλουθα ση εία. Επανέλεγχο Δεν ενεργοποιείται • Εχει καεί η ασφάλεια ή έχει ενεργοποιηθεί ο ασφαλειοδιακόπτης. • Έχουν εξαντληθεί οι μπαταρίες του τηλεχειριστηρίου. • Έχει ρυθμιστεί ο χρονοδιακότης. Δεν...
Page 26
Η ένδειξη εκπο πή “ ” δεν ανάβει ποτέ. Συ πτώ ατα Αιτία Λόγο και εξήγηση Οι εντολέ από το τηλεχειρι- • Ελέγξε εάν οι μπαταρίες Οι εντολέ του τηλεχειριστηρίου στήριο δεν εταδίδονται ακό η του τηλεχειριστηρίου δεν μεταδίδονται γιατί δεν έχει κι...
Page 27
Οι ακόλουθες ενδείξεις αναδεικνύουν σφάλμα ή πρόβλημα Λυχνία Λυχνία λειτουργίας Σφάλμα Οθόνη χρονοδιακόπτη (λάμψεις/δευτερόλεπτο) Σφάλμα λογισμικού εσωτερικής μονάδας Σφάλμα επικοινωνίας εσωτερικής/εξωτερικής μονάδας Σφάλμα ανεμιστήρα εσωτερικής μονάδας Σφάλμα στον αισθητήρα εσωτερικής θερμοκρασίας Σφάλμα στον αισθητήρα θερμοκρασίας στο στοιχείο Σφάλμα ανίχνευσης διαρροής ψυκτικού...
Page 28
Ενεργοποιήστε την εγγύηση σας... σε Inventor Συνδεθείτε στο site της στον ακόλουθο σύνδεσµο http://www.inventoraircondition.gr/ egiisi-inventor/ απλά Επιλέξτε τον τύπο του προϊόντος (κλιµατιστικό ή συσκευή) για το οποίο θα ενεργοποιηθεί η εγγύηση Επιλέξτε την εγγύηση που αντιστοιχεί στο προϊόν που έχετε στην κατοχή σας...
Page 30
Cuprins Informatii importante cu privire la siguranta --------------------------------------------------------- Sfaturi pentru economie de energie -------------------------------------------------------------------- Denumirea partilor componente ------------------------------------------------------------------------ Operarea manuala -------------------------------------------------------------------------------------------3 Schimbarea directiei uxului de aer --------------------------------------------------------------------4 Mentenanta --------------------------------------------------------------------------------------------------5 Functionarea si performantele aparatului ------------------------------------------------------------7 Instalarea ------------------------------------------------------------------------------------------------------8 Defectiuni si cauze -----------------------------------------------------------------------------------------9 Defectiuni si cauze (telecomanda) ---------------------------------------------------------------------9...
INFORMATII IMPORTANTE CU PRIVIRE LA SIGURANTA ATENTIE Danger Nu instalati acest aparat de unul singur. Doar personalul autorizat si calificat poate efectua instalarea. PERICOL Nu faceti dumneavoastra lucrari de service. Aceasta unitate nu are nici o parte componenta care poate fi reparata de utilizator. Deschiderea sau inlaturarea carcasei va poate expune la tensiune periculoasa.
SFATURI PENTRU ECONOMIE DE ENERGIE Urmati sfaturile mentionate mai jos pentru a asigura o functionare economica a aparatului (consultati capitolul corespondent din manual) Ajustati directia fluxului de aer asa incat sa nu fie pe directia geamului. Ajustati temperatura camerei pentru a va asigura conditii confortabile si pentru a evita excesul temperaturile extreme.
DENUMIREA SI FUNCTIILE a) Unitate interioara b) Unitate exterioara c) Telecomanda d) Gura admisie aer e) Gura evacuare aer f ) Priza evacuare Flaps pentru ajustarea directiei h) Conducta conectoare fluxul de aer (evacuare) j) Priza admisie aer (cu filtru de aer) Furtun scurgere k) Pompa de scurgere a unitatii interioare l ) Receptor semnal infrarosu...
Page 34
AJUSTAREA FLUXULUI DE AER Tip CASETA In timpul functionarii aparatului, puteti ajusta directia fluxlui de aer cu ajutorul flapsului. 1. Stabiliti directia dorita a fluxului de aer. Apasati butonul SWING pentru a aduce flapsul in pozitia dorita si apasati butonul inca odata pentru a alege pozitia.
MENTENANTA AVERTIZARE Curatarea unitatii interioare si a telecomenzii. ATENTIONARI Folositi o carpa uscata pentru a sterge unitatea interioara si telecomanda. Puteti folosi si o carpa umeda in cazul in care unitatea interioara este foarte murdara. Niciodata nu folositi o carpa umeda atunci cand curatati telecomanda. Nu folositi o laveta tratata chimic pentru curatare.
Page 36
Tip CASETA 1. Deschideti grilajul Impingeti usor, simultan, clemele grilajului catre centru, cum este indicat in schita A. Dupa, trageti grilajul in jos. Atentionari : Deconectati cablurile din cutia de control inainte de a efectua orice lucrare. 2. Trageti grilajul (impreuna cu filtrul de aer, conform schitei B). 3.
FUNCTIONAREA SI PERFORMANTELE APARATULUI Functia de protectie de 3 minute. O functie de protectie va preveni pornirea aparatului timp de 3 minute dupa oprire. Pana de curent Unitatea se va opri in cazul unei pene de curent Indicatorul luminos de functionare al unitatii interioare va incepe sa clipeasca atunci cand alimentarea cu energie electrica a revenit.
INSTALAREA Locatia In timpul racirii, aparatul va elimina umiditatea din aer. Asigurati-va ca scurgerea se va face departe de aparat. Montati unitatea interioara la cel putin 1M dinstanta de cel mai apropiat televizor sau aparat de radio pentru a evita aparitia interferentelor. Aparatele radio puternice sau alte aparate care transmit pe unde radio inalte pot afecta functionarea aparatului.
DEFECTIUNI SI CAUZE Inainte de a contacta departamentul de service, consultati lista de mai jos. Verificarea Aparatul nu functioneaza Siguranta electrica este sarita sau comutatorul este oprit. Bateriile telecomenzii sunt descarcate. Temporizatorul este programat. Aparatul nu incalzeste sau nu raceste. Gura de admisie a unitatii exterioare este blocata.
Page 40
Indicatorul de transmitere " " nu apare Simptome Solutia posibila Cauze Verificati daca bateriile Semnalul nu este transmis Semnalul telecomenzii nu sunt descarcate deoarece sursa de alimentare este transmis chiar daca este oprita. apasati butonul ON/OFF Afisajul nu porneste Simptome Solutia posibila Cauze Verificati daca moul FAN...
Page 41
Urmatoarele mesaje vor fi afisate la aparitia unei erori sau probleme Indicator Numarul de flashuri pe secunda Mesajul afisaj Defectiunea Crt. luminos Oprit Eroarea placii de baza a unitatii interioare Eroare de comunicare intre unitatea Oprit interioara si cea exterioara. Defectarea ventilatorului unitatii interioare.
Page 42
Activati-va garantia... Accesati link-ul de mai jos: https://www.inventoraerconditionat.ro/ certificatul-de-garantie-inventor- aer-conditionat-si-electrocasnice Pasi Alegeti tipul de produs pentru simpli! care vreti sa activati garantia (aparat de aer conditionat, alt aparat electrocasnic). Alegeti tipul de garantie corespunzator produsului achizitionat. Completati formularul cu informatiile cerute (numele...
Page 44
CASSETTE TYPE Scan here to download the latest version of this manual. Σαρώστε εδώ για να κατεβάσετε την τελευταία έκδοση του εγχειριδίου.
