U-MATCH AIR CONDITIONERS
3.
Removal
of
evaporator
Disassembly of External casing cabinet
Remark: Make sure the power supply is cut off before disassembling and protect all the parts during disassembly.
Step
1. Disassembly of
fastening
screws
between
cover
plates
2.
Disassembly
ofexternal
casing
cabinet
Illustration
MAINTENANCE
Remove the evaporator. Removed
evaporator is shown in the graph.
Handling Instruction
Disassemble the fastening screws
between right and left panels and upper
cover plates. Disassemble right and left
panels. (As is shown in the graph,
circle represents screws. )
Disassembled external casing cabinet
is shown in the graph.
