U-MATCH AIR CONDITIONERS
Disassembly of air deflecting plate modules
Remark: Make sure the power supply is cut off before disassembling and protect all the parts during disassembly, especially the
joints of the air deflecting plate.
Step
Disassembly of
air
deflecting
plate modules
Disassemble of water-containing plate modules
Remark: Make sure the power supply is cut off before disassembling and protect all the parts during disassembly.
Step
Disassemble
of
water-containing
plate modules
Disassembly of fixing plate modules for air sweeping fans
Remark: Make sure the power supply is cut off before disassembling and protect all the parts during disassembly, especially the
connection part of air sweeping fans.
Step
Disassembly of
fixing
plate
modules for air
sweeping fans
Illustration
Illustration
Illustration
MAINTENANCE
Handling Instruction
Remove the air deflecting
plates from the air deflecting
plate support assembly, and
then remove both ends from
the air sweeping motor. joint
(As is shown in the graph,
arrow represents the support
assembly and circle the air
sweeping motor joint.)
Handling
Instruction
Disassemble
screws shown in the
graph
screwdriver
screws on both left
and
right),
remove
water-containing
plate modules.
Handling Instruction
Disassemble
screws on both ends of
fixing plate modules
for air sweeping fans (1
for both sides) and
remove the fixing plate
modules
for
sweeping fans from the
air deflecting support.
151
4
with
(two
and
the
the
air
