STEAM TREAT
TM
Use this option for heavily soiled loads that need improved stain
treatment, loads with multiple types of stains, or loads you
suspect as having stains, but are afraid may have been missed
(no sorting or searching for stains). When STEAM TREAT
TM
is
selected, the water temperature of the selected wash cycle is
automatically
set to warm. The water will then be slowly heated
to the temperature
selected, along with steam, to aid in stain
removal. This option will provide optimal removal of organic
stains such as blood. This option is available on the following
cycles: Normal/Casual,
Bulky Bedding, Kidswear, Heavy Duty,
Whitest Whites.
TIMED OXl
TM
Use this option when using an oxygen based stain fighter or
color-safe bleach in the dispenser. Selecting this option will
ensure these products dispense during the wash cycle at the
proper time for improved performance.
Add using the Oxi / Color-safe bleach section of the
dispenser drawer.
Autosoak
Use the Autosoak option to remove small spots or stains on
fabrics. This option provides up to a 30-minute soak time prior
to the start of the selected cycle.
Using the Autosoak
option: The Autosoak option provides a
soak time with warm or cold water followed by drain.
1. Select desired cycle.
2. Choose the desired temperature.
3. Select Autosoak. When selected, the bottom half of the
button indicator will glow green.
4. Select and hold START (approximately
1 second).
2nd Rinse
A second rinse can be used to aid in the removal of detergent or
bleach residue from garments. This option provides an additional
rinse with the same water temperature as the normal rinse. This is
the default rinse setting for the Whitest Whites cycle. When 2nd
Rinse is selected, the top half of the button indicator light will
glow green.
SkinCare Rinse II
This option provides the best rinse level, to allow for even better
detergent removal. Press the 2nd Rinse/Skincare
Rinse II button
twice to select this option. When Skincare Rinse II is selected, the
bottom half of the button indicator light will glow green.
Button Sounds
Button sounds are used to notify you of what has been selected
or to let you know when something is not available. Button
sounds may be turned on or off by selecting BUTTON SOUNDS.
Save Energy Plus
The Save Energy Plus option allows you to increase your energy
savings on the higher temperature cycles (Whitest Whites and
Heavy Duty) while maintaining cleaning performance
by
lengthening the wash time by only 10 minutes.
Delay Start
To begin the wash cycle later, select DELAY START until the
desired delay time (in hours) shows in the Estimated Time
Remaining display, and then select START. The countdown to the
wash cycle will show in the display window, and the button
indicator will blink until the cycle begins.
IMPORTANT: When delaying a cycle, use only powdered
detergents in the high efficiency "HE" detergent compartment
since liquid detergents may seep out of the compartment
during
DELAY START, before the wash cycle begins.
Cycle Signal
This signal is helpful when you are removing items from the
washer as soon as it stops. Select Loud, Soft, or Off.
Preset cycle settings of Water Temperature, Spin Speed, and
Rinse Options can be changed. You can change a modifier after
starting a cycle anytime before the selected Modifier begins. Not
all Modifiers are available with all options and cycles. Available
modifier settings will glow amber. Current selections will glow
green. If an option is unavailable with a selected cycle, the light
will not illuminate.
MODIFIERS
I m
Steam Sanitize
m
Extra Nigh
I•
Hot
High
T_t_ °
Warm*
coN,.o_I•
Medium
Heavy
I•
Warm
Low
Normal
Coot
Extra Low
I
Light
I
CON
I
No Spin
©
©
©
Soil Level
, Wash Temp
Spin Speed
To change cycle time, select SOIL LEVEL button.
To change the water temperature,
select the WASH TEMP
button until the desired setting glows green.
To change the spin speed, select the SPIN SPEED button
until the desired setting glows green.
18
