REDMIKE Share: Controls and Connections
1. POWER SWITCH:
2. POWER/CHARGE INDICATOR:
this light glows blue when turned
on and turns off to indicate low
battery level. When charging, the
light glows red.
3. AUDIO INPUT: plug a laptop, MP3
player or other audio device into
this jack to wirelessly transmit the
audio signal to be played through
the system.
4. CHANNEL SELECT SWITCH
(CH A/B): Located in the battery
compartment, this switch is set to
Channel B at the factory.
5. CHARGER INPUT: Plug the
charging cable from the REDMIKE
cradle charger or into this jack.
3
2
1
5
4
