TechniSat DIGIT MF4-K CC User Manual page 64

Cable
input
Mains power
Audio output
socket
digital (electrical)
LED display
Programme select
Card reader for Smartcard:
> Insert the Smartcard (gold-coloured chip at the bottom, and in the
direction of insertion) carefully into the card reader as far as it will go.
Cable SCART socket
VCR
output
Audio outputs
analogue
Inserting the CI module:
> Please follow the instructions of the manufacturer of the CI
module and card.
> Insert the desired Smartcard in the appropriate CI module.
> Now insert the CI module carefully in the slot provided.
RS 232
interface
64
On/Stand-by
up/down
SCART socket
TV
Audioausgang
digital (optisch)
