Routing
To route multiple sources to Groups, Main Outputs or Auxiliaries press and hold the required number key in the
GROUP, AUX or MAIN OUTPUTS area. Existing sources will be indicated by the screen, source key LEDs and
ACCESS Key LEDs. Press the keys for the required sources then release the destination key.
To access additional Tracks (if available) press the left/right arrow keys above the screen. The red hashing will
move to the next/previous row of Track numbers.

Path Routing with the Access Keys

The ACCESS Keys on the Fader Strips, can be used for routing, either by using other ACCESS Keys or any of the
routing controls associated with the Routing Screen. When an ACCESS Key is used for routing a Track then it can
only be used as a routing source.
To route a path to destinations press and hold the ACCESS Key or main output for a Channel, Track Group then
press the keys for valid destinations on the routing screen or other Access Keys.
Existing routing of the path will be indicated by the illumination of LEDs above ACCESS keys and integral LEDs
in the keys around the Routing Screen illuminating red.
The integral LEDs in the keys for the selected destinations will illuminate red and the Routing Screen will show
routing changes.
Clearing Routing
Clearing routing (or de-routing) can be achieved by the same actions as doing the routing (to toggle the
particular routing selection off again). This will de-route paths one at a time. Alternatively, multiple paths can be
de-routed in one operation by using the Clear Routing dialogue box.
To clear routing press the left and right arrow keys above the routing screen at the same time or right click on the
routing screen. Click the Clear Routing option. In both cases, the Clear Routing dialogue box will be displayed.
Click in the required Source and Destination check boxes and click OK.
The selected routing will be cleared (de-routed) and the routing screen will be updated as applicable.
Clear Routing does not affect monitoring selections made via the SELECT Panel.
Routing Screen Display Options
To change the background colour of the routing screen double click anywhere on the background. A Colour
dialogue box will be displayed, click on the required colour then click OK. The background colour will be
changed as selected.
Other Routing Screen Options
Move the trackball pointer across to the routing display and right click. The pop-up routing menu will appear
next to the trackball pointer.
