Tools Menu

Routing Assistant

Routing Assistant currently only works with Offline Encore. Please note, however, that the currently released
version of Offline Encore precedes the introduction of Routing Assistant.
It is used to display and modify routing. This allows a new Desk Setup that has been created Offline to have
routing settings that will be applied when the Desk Setup is transferred back to the online system.
Routing Assistant displays an overview of selected routing in a matrix style. Any changes made to routing are
shown immediately. If the assistant is used offline, then routing changes are saved in the desk setup. Changes
will be affected on the console when the Desk Setup is restored to Online Encore and loaded.
The first time Routing Assistant is opened, the display will be blank. After this, the Assistant will open displaying
the same routing blocks that were displayed the last time it was closed.
Click on any block to make that one the active block. It will change colour to indicate this.
Menus
File
Exit Alt+X: Allows the user to exit the program in a controlled way.
Configure
Configure Blocks: allows the user to decide which blocks are to be displayed on screen. Click the options
required then clock OK.
Arrange Blocks: Arranges the blocks in a uniform manner from the top left hand side of the screen.
Remove Current Block: Removes the highlighted block from screen.
Clear Current Block: Clears all the routing for the highlighted block.
Auto Route Current Block: Presumes a 1:1 relationship between source and destination. This is most useful for
example when multitrack recording, so that Channel 1 is sent to Track 1, Channel 2 to Track 2 etc.
Pre/Post: Allows the user to toggle between pre-fade send, and post-fade send. This can either be done on a
block by block basis, or individually.
Zoom In / Zoom Out: Changes the magnification of the screen. Page Up and Page Down (or the + & - keys) on
the keyboard can also be used for this.
Options
Colours: Allows the user to set the screen colour scheme for the Active Block, the Inactive block and the screen
background.
Show Separators: These are two scaleable guidelines on screen, one vertical one horizontal and they aid the
navigation of large screens.
