1.5.2 Rear View
No. Name
1
USB Port
2
Ethernet Port
3
Terminal Block
4
Power In
5
Power Out
4
1
2
Figure 1-2
Function
2 USB ports for installing portable storage devices.
A plug for inserting an Ethernet cable to build the network
connection.
The connectors for digital inputs, relay outputs, RS±485, Wiegand
interface, and the GPS module (only for GV-Video Server Hardware
Version 2.0).
A plug for power input.
A plug for power output.
3
4
5
