3. TECHNICAL SPECIFICATIONS AND DIMENSIONS

Technical specifications

3.1.
The hot water pellet boilers in the "COMPACT 24" range are pellet boilers for the production of hot water
with a steel structure, which use solid biomasses in the form of pellets as fuel. The boiler is designed for
connection to heating systems and to the Domestic Hot Water system.

Compact 24 hot water boiler description

3.2.
The "COMPACT 24" hot water pellet boiler heat exchanger complies with the operating requirements
of this type of appliance, as set out in the operation standard:
Programmable
electronics to
control the
boiler functions
Cast iron grate
unit for long-
lasting durability
Large ash tray for
a weekly clean
Technical specifications and dimensions
COMPACT 24 BOILER
USE AND INSTALLATION MANUAL
EN 303-5/2000 –
Technical dept. - All rights reserved - Reproduction prohibited
Chapter
3
page 9
Filling tank provided
with a capacity of
approximately
110 litres
(about 70 kg)
Domestic hot
water exchanger
