6. HYDRAULIC AND ELECTRICAL CONNECTIONS

Hydraulic connection

6.1.
IMPORTANT!
If the boiler installation envisages interaction with another existing system complete
with another heating appliance (gas boiler, methane boiler, diesel boiler, etc....), ask for
qualified personnel for assistance to ensure the system is compliant with the applicable
laws in force.
The manufacturer will not be held liable for property damage or personal injury or in the
event of failed or incorrect functioning, if the above warnings are not adhered to.
50
95
1
EXHAUST
2
SAFETY VALVE
3
FILLING
4
DOMESTIC WATER OUTLET
1/2"G MALE
Make the connections to the corresponding unions illustrated in the above diagram, avoiding any tension and
undersizing of pipes.
Hydraulic and electrical connection
COMPACT 24 BOILER
USE AND MAINTENANCE MANUAL
69
1
2
3
5
6
7
50
DOMESTIC WATER INLET
1/2"G MALE
HEATING RETURN
3/4"G MALE
HEATING FLOW
3/4"G MALE
Technical dept. - All rights reserved - Reproduction prohibited
Chapter
6
page
95
69
196
20
