3. O
VERVIEW
p
3. 1.
URpOSE Of
The 2-pole ASYS is a two-way, single phase automatic switch powered by two inde-
pendent synchronous or asynchronous AC power supply sources.
ASYS provides redundant power, it makes a rapid switch from one source to the oth-
er in the event of a fault to the power supply used to power the load.
One of the two sources can be designated as the preferred power supply, to which
the ASYS will supply the load. It remains there until different designations or faults
require it to be switched to the alternate source.
The ASYS is fitted with a block diagram with LED indicators, capable of providing all
information concerning equipment operation status, together with the power source
priority selection which enables trained operators to make full use of the apparatus.
4. U
NpACkING AND INSTAllATION
D
4. 1.
ElIVERy AND
The goods have been checked thoroughly before dispatch. On receipt, check the
packaging and ensure that the contents are undamaged. Any damage or missing
parts must be reported to the supplier as soon as possible.
ASYS is available in 2 models (see chapter 7 for characteristics):
I
4. 2.
NVENTORy
– ASYS module
– 2 pluggable input power cable (for ASYS16 - 230 model only)
– Screw sets (4 screw and 4 cage nuts)
– 2 bracket kits for rack mounting
– 2 bracket kits for vertical mounting
– User Manual
NOTE: An approved power cable greater or equal to H05VV-F, 3G, 0.7mm² must be
used.
ASyS TRANSfER SWITCH
S
TORAGE
l
IST
ASYS
16 A Transfer System
ASYS16 -120
ASYS16 - 230
