E
4. 7.
NVIRONmENTAl REqUISITES
It is necessary to leave a minimum space of a few centimetres around right side, left
side and rear side to allow a flow of air and to provide access to the interface.
5. p
RESENTATION
f
5. 1.
RONT
The front of the ASYS TRANSFER SWITCH with its LED display and interfaces:
O
perating panel
R p
5. 2.
EAR
The back of the ASYS with its connectors, terminals and interfaces:
2 Input IEC 320 C20
2 Input Fuse
2 Input Power cord AWG 12x3C / 20A
2 Input Fuse
p
ANEl
ANEl
ASyS 16A-230:
1 Output IEC320-C19
ASyS 16A-120:
ASYS
S
ervicing acceSS
2 x 10A thermal protection
2 x 3 Output IEC320-C13
4 Output NEMA 5-20R
16 A Transfer System
D
(
ry cOntact
cOmmunicatiOn acceSS
IOMASY160810-GB_00
)
7
