  • Page 1 _________ l � -' -------- - - Модульный автоматический реверсивный рубильник с дистанционным управлением Socomec ATyS t M - руководство по эксплуатации. Юниджет. Постоянная ссылка на страницу: https://www.uni-jet.com/catalog/ustrojstva-avr/socomec- atys-t-m.html...
  • Page 2 ATyS t M Automatic Transfer Switching Equipment www.socomec.com...
  • Page 3 To download, brochures, catalogues and technical manuals. ATyS t M - 542 931 C - SOCOMEC...

  • Page 4: Table Of Contents

    ..............20 ATyS t M - 542 931 C - SOCOMEC...
  • Page 5 ............30 ATyS t M - 542 931 C - SOCOMEC...
  • Page 6 This page intentionally left blank ATyS t M - 542 931 C - SOCOMEC...

  • Page 7: General Safety Instructions

    One must also refer to and respect markings on the product prior to installation and commissioning for values and limits speciic to that product. • Using the product outside the intended scope, outside SOCOMEC recommendations or outside the speciied ratings and limits can cause personal injury and/or damage to equipment.

  • Page 8: Introduction

    Transformer Management Management atyS d S atyS d M Small Genset RTSE (DPS) atyS d with DPS RTSE (DPS) Side by Side atyS S (RTSE) atyS r ATyS Configuration Small Genset RTSE RTSE The UL version of ATyS r is available from 100 - 400A ATyS t M - 542 931 C - SOCOMEC...

  • Page 9: The Atys M Range Key Features

    Non-critical ATyS loads Critical loads > Network / Genset > Network / Genset genset applications for > Network / Network ATyS ATyS Standby power Non-critical Non-critical loads loads Critical Critical loads loads ATyS t M - 542 931 C - SOCOMEC...

  • Page 10: Selection Guide

    * 3 inputs / 3 outputs (programmable). ** Product reference is different: communication by RS485 connection (MODBUS) allows up to 31 ATyS M to be connected to a PC or a PLC over 1500 m. ATyS t M - 542 931 C - SOCOMEC...

  • Page 11: Quick Start

    A separate sheet for each language. • E: No stop in O position • F: 2s stop in 0 position CORPORATE HQ CONTACT: SOCOMEC SAS, 1-4 RUE DE WESTHOUSE, 67235 BENFELD, FRANCE Priority G-H • G: With priority • H: Without priority...
  • Page 12 LED OFF Source 1 not Source 2 not screws for screws for availlable availlable 1 module 2 modules - a timer is - a timer is Pozidriv PZ2 - 1 Nm counting counting blinking down down ATyS t M - 542 931 C - SOCOMEC...

  • Page 13: Atys T M Versions

    The power supply of ATyS t M is required to be 220 VAC -20% to 240VAC +20% at a frequency of 50/60 Hz and has been developed so as to meet most network conigurations. Version 230 / 400 VAC Umax Umin Ph-N Ph-Ph ATyS t M - 542 931 C - SOCOMEC...

  • Page 14: Optional Accessories

    M has integrated measurement and power supply circuits, a neutral connection is required for 400 VAC three-phase applications. When no neutral connection is available this autotransformer (400/230 VAC, 400 VA) provides the 230 VAC required for the ATyS M to function. ATyS t M - 542 931 C - SOCOMEC...

  • Page 15: Technical Data

    ** AC 33iB 160A according to GB 14048.11. This is a class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. ATyS t M - 542 931 C - SOCOMEC...

  • Page 16: Environmental Conditions

    • Maximum storage temperature: +55 °C • 80 % humidity without condensation at 55 °C IP rating • IP41 in the SOCOMEC polycarbonate modular enclosure see page 20 1 ¡ ¡ • IP2x for non-enclosed modular product Protection class: Class 1...

  • Page 17: Product Installation

    STEP 1 Posidriv PZ2 2,2 lb-in 0,25 Nm Posidriv PZ2 Posidriv PZ2 8.2. recommanded orientation Recommended 8.3. Dimensions 8.4. back plate mounted MAX : 2 73,5 6 mounting brackets 6x M6 screw - 2,5 Nm ATyS t M - 542 931 C - SOCOMEC...

  • Page 18: Din Rail Mounted

    8.5. DIN rail mounted Tighten to avoid movement on the DIN rail. DIN RAIL IEC 60715 Posidriv PZ1 1 Nm ATyS t M - 542 931 C - SOCOMEC...

  • Page 19: Installation Of Optional Accessories

    Source I Source II Make sure that the bridging bar is itted to the correct set of terminals. There are two references available: one for ratings up to 125A, and another for 160A rating. ATyS t M - 542 931 C - SOCOMEC...

  • Page 20: Terminal Shrouds

    9.4. Terminal shrouds Ref. 2294 4016 °C °C °K °K 9.5. sealable cover Ref. 1359 0000 ATyS t M - 542 931 C - SOCOMEC...

  • Page 21: Installing Within The Atys M Enclosure

    385 mm 225 mm (M6) 193 mm 10.1.1. Wiring in a polycarbonate enclosure example: neutral on the right Max cable size 25 mm²  10.1.2. Extension unit Ref. 1309 9007 Enables you to allocate additional space to the polycarobonate enclosure (ref. 1309 9006). ATyS t M - 542 931 C - SOCOMEC...

  • Page 22: Connection Of The Power Circuits

    (mm **Max cable size recommended (mm *With extension unit. ** Maximum cable size for rigid cable is 50 mm . For larger terminations use the power connection terminals ref. 1399 4017. Not compatible with aluminium cables ATyS t M - 542 931 C - SOCOMEC...

  • Page 23: Network Configurations

    63 64 73 74 rM32 2p rM32 2p 2 a aM 2 a aM 1 a aM 1 a aM 400 / 230 v 400 / 230 v 400 va 400 va source I source II ATyS t M - 542 931 C - SOCOMEC...

  • Page 24: Connection Of Control/Command Circuits

    Maximum control cables length = 10 m. In case of longer distance, use control relays. Source must always be connected as show above. Ensure that the product is in Manual Mode (front cover open). ATyS t M - 542 931 C - SOCOMEC...

  • Page 25: Terminal Connectors Designation

    1309 0011 250V AC 5A AC1 21/22/24 Changeover switch in position II 24VDC 2A AC13 - 250VAC - 2A 01/02/04 250V AC 5A AC1 Changeover switch in position 0 24VDC 2A AC13 - 250VAC - 2A ATyS t M - 542 931 C - SOCOMEC...

  • Page 26: Auxiliary Contact Operating Schedule

    12.2. auxiliary contact operating schedule Position I Position 0 Position II C.A. Position I 11-14 Closed 11-12 Open C.A. Position 0 01-04 Closed 01-02 Open C.A. Position II 21-24 Closed 21-22 Open ATyS t M - 542 931 C - SOCOMEC...

  • Page 27: Operation

    5. manual switching • Insert the Allen key (5.0 mm) provided and turn to switch manually. • Manual operation is not possible when padlocked. 13.1.2. reset Operating fault reset Open and re-close the AUT/MAN cover ATyS t M - 542 931 C - SOCOMEC...

  • Page 28: Manual Mode

    Refer to section «8.1. Changing the padlocking coniguration», page 16 Locking is only possible in manual mode (cover open). 4 mm min Pull on the locking handle to enable the interlock. Lock 3/16” min by inserting a padlock into the oriice provided for this 8 mm min purpose. 5/16” min ATyS t M - 542 931 C - SOCOMEC...

  • Page 29: Programming

    Stop in 0 position: E-F • E: No stop in O position • F: 2s stop in O position Fault reset Type of application: G-H • G: With priority • H: Without priority RT: 0-30 min. ATyS t M - 542 931 C - SOCOMEC...

  • Page 30: Sealable Configuration Cover

    13.6. Possible actions Once in automatic mode, it is possible to: • Run a source / source loss sequence • start a restoration sequence source / source autoMatic Mode loss of source Source return: source source ATyS t M - 542 931 C - SOCOMEC...

  • Page 31: Preventative Maintenance

    Check the following parameters: - network type: Must be a 3 phase network + neutral (or transfor- mer), - nominal voltage: Must be between 176 and 288 Vac, - nominal frequency: Must be between 45 and 65 Hz. ATyS t M - 542 931 C - SOCOMEC...
  • Page 32 Check RT (Main Return Timer) configuration which can be When RT reaches zero the configured between 0 and 30min. switch will operate to position 0 before finally transferring to The changeover will only take place at the end of RT. its priority position. ATyS t M - 542 931 C - SOCOMEC...
  • Page 33 Non-contractual document. © 2016, Socomec SAS. All rights reserved.
