p
2. 3.
ACkAGING
All packaging material must be recycled in compliance with the laws in force
in the country where the system is installed.
W
2. 4.
ARNING
– It is absolutely necessary to earth the ASYS before connecting any upstream and
downstream supplies.
– The Installation of the ASYS may only be carried out by qualified technical person-
nel.
– Even if the ASYS output has been switched off, hazardous voltages are present
within the ASYS; any operation that requires the unit to be opened and/or re-
moved may be carried out by authorized technical personnel only.
– Do not remove the cover without completely disconnecting the ASYS from the
input supplies 1 and 2.
– User or Operator can intervene in ASYS on condition that the instructions of con-
nection presented below are respected.
ASYS Transfer System fed by two independent UPS
Mains 1 UPS 1
Mains 2 UPS 2
4
IOMASY160810-GB_00
S 1
S 2
ASYS
16 A Transfer System
ASYS 16A
Load
