Specifications - socomec Asys 16 A Transfer System Installation And Operating Manual

C
7. 3.
OmmUNICATIONS
Dry Contact (DB-9, pin type)
m
7. 4.
ECHANICAl
Items
Dimension
Weight
Packaging sizes
Structure
Material
Colour
E
7. 5.
NVIRONmENT
Items
Operating temperature
Storage temperature
Storage humidity
Operation humidity
Operation Altitude
Audible noise
Cooling
IP Protection
12
IOMASY160810-GB_00
PIN N°.
PIN 4
PIN 8
PIN 1
PIN 7
PIN 9
PIN 5
f
EATURES
W = 430mm D = 315mm H = 44mm (1U)
W = 585mm D = 425mm H = 184mm
Rack Mount Unit (1U)
-25 °C to 70 °C Continuous
20%to 85% No condensing
≤ 1000m (without downgrading)
ASYS
Definition
Input Mains 1 (OK / NG)
Input Mains 2 (OK / NG)
Over Temperature
Overload
SUM Alarm
Common
Specification
5kg
Metallic Case
Pantone 432C

Specifications

0 to 40 °C
10% to 90%
< 25dBA
Natural Cooling
IP 30
16 A Transfer System
