SHB210 Socket M Half-Size SBC User's Manual
1.1

Specifications

®
CPU: Intel Core
M
processors
System Chipset: Intel
CPU Socket: Socket M
Front-Side Bus: 533/667 MHz
BIOS
Award PnP Flash BIOS
System Memory
Two x 200-pin DDR2 SO-DIMM sockets
Maximum up to 4GB DDR2 memory
Support DDR2 400/533/667 memory
L2 Cache: integrated in CPU
IDE Interface
One IDE connector and up to two IDE devices, Ultra DMA
ATA33/66/100 supported
FDD Interface
Supports up to one drives
Compact Flash Socket
One Compact Flash
Onboard Multi-I/O
Parallel Port: one bi-directional with ECP/EPP/SPP support
Serial Port: one port for RS-232/422/485 (COM1) and one
port for RS-232 (COM2)
Floppy controller: supports one drives (1.44MB for each)
USB Interface
Six USB ports compliant with USB Spec. Rev. 2.0
VGA Controller
®
Intel Graphic Media Accelerator 950 integrated on Intel
945GM
2
™ ™
2 Duo/Core Duo/Core
®
945GM/ICH7M-DH
®
Type II Socket
™ ®
/Celeron
Solo
®
Introduction
