2.4.13
External Mouse/Keyboard Connectors:
CN9/CN13
The board provides a keyboard (CN13) and Mouse (CN9) interface
with two 5-pin connectors.
2.4.14
SYSTEM FAN1/FAN2/FAN3 Connectors:
You can connect the system cooling fan cable to FAN1/FAN2/FAN3 for
system cooling fan power.
Pin
1
2
3
2.4.15
Ethernet Connector 2 External Speed LED:
CN25
Pin
1
100, Low Active
2
3.3V
3
Gigibit, Low Active
Jumpers and Connectors
SHB210 Socket M Half-Size SBC User's Manual
Clock
1
Data
2
No Connection
3
GND
4
Power
5
Signal
FAN1/FAN2/FAN3
Ground
+12V
Rotation Detection
Signal
CN25
19
