2.3

Jumper Settings

Proper jumer settings configure the SHB210 to meet your application
purpose.

2.3.1 COM2 Mode Select Jumpers: JP2, JP3, JP4

These jumpers select the COM1 port's communication mode to
operate RS-232 or RS-422/485.
Description Function
COM1 RS-232
(Default)
RS-422
RS-485

2.3.2 Compact Flash Setting Jumper: JP6

Use this jumper to set Master/Slave Compact Flash interface.
Description Function Jumper Setting
Master
CF
(Default)
Master/Slave
Jumpers and Connectors
SHB210 Socket M Half-Size SBC User's Manual
Jumper Setting
JP2
JP2
JP2
Function
JP6 Slave
JP3 JP4
JP3 JP4
JP3 JP4
Jumper Setting
JP6
7
