Before installing the processor, please access Intel

detailed information http://www.intel.com .

3.1

The Intel® Pentium® M Processor is available as a boxed processor

for laptop computers in the micro-FCPGA form factor. Intel

recommends the processor should be installed by a computer

professional since this electronic device may cause serious damage to

the installer, system and processor if installed improperly.

Important: Before attempting to install a new processor, carefully

review the documentation that came with your system and make sure

that you will not be voiding your warranty by opening the computer or

replacing your processor.

Instructions

1. Make sure that your system can accommodate the Intel

Pentium M Processor that you want to install. Check for

motherboard, BIOS, and thermal compatibility by using the

manufacturer's documentation for the laptop computer, or by

contacting the vendor if necessary. This processor should only

be installed in systems supporting the Intel Pentium M

Processor.

Important Notes: Do not use a Intel Pentium M Processor in a

desktop system and do not use a desktop processor in a Intel

Pentium M Processor notebook. Since these processors have

different electrical specifications, damage to the processor and

system can occur.

2. Obtain access to your processor socket as described in the

documentation for your system.

SHB210 Socket M Half-Size SBC User's Manual

Hardware Installation

C h a p t e r 3

website for more
