SHB210 Socket M Half-Size SBC User's Manual

2.3.3 Compact Flash Voltage Selection Jumper: JP8

This jumper is to select the voltage for Compact Flash interface.
Description Function Jumper Setting
3.3V
LCD
(Default)
Voltage

2.3.4 COM1 DCD and Voltage Selection Jumper: JP1

Jumper Description Jumper Setting
COM1 DCD Normal
& RI
(Default)
Voltage
Selection
12V

2.3.5 CMOS Clear Jumper: JP7

You may need to use this jumper is to clear the CMOS memory if
incorrect settings in the Setup Utility.
Description Function
Normal
CMOS
(Default)
8
Function
JP8 5V
Description
JP1 5V
JP1 DCD/5V
RI/12V
Jumper Setting Function
JP7 Clear
CMOS
Jumpers and Connectors
Jumper Setting
JP8
Jumper Setting
JP1
JP1
Jumper Setting
JP7
