Modes; 13-Channel (Tour) - SHOWTEC Spectral CYC2000 Product Manual

DMX Control TOUR
Channel
1
2
3
4
5
6
7
8
9
Value
Dimmer
000 – 255
0 – 100 %
Red
000 – 255
0 – 100 %;
(only if CH9 161-255)
Green
000 – 255
0 – 100 %;
(only if CH9 161-255)
Blue
000 – 255
0 – 100 %
White
000 – 255
0 – 100 %
Amber
000 – 255
0 – 100 %
Macro Colors
000 – 010
No Function
011 – 030
Red 100% / Green Up / Blue 0%
031 – 050
Red Down / Green 100% / Blue 0%
051 – 070
Red 0% / Green 100% / Blue Up
071 – 090
Red 0% / Green Down / Blue 100%
091 – 110
Red Up / Green 0% / Blue 100%
111 – 130
Red 100% / Green 0% / Blue Down
131 – 150
Red 100% / Green Up / Blue Up
151 – 170
Red Down / Green Down / Blue 100%
171 – 200
Red 100% / Green 100% / Blue 100% / White 100% / Amber 100%
201 – 205
White 1: 3200K
206 – 210
White 2: 3400K
211 – 215
White 3: 4200K
216 – 220
White 4: 4900K
221 – 225
White 5: 5600K
226 – 230
White 6: 5900K
231 – 235
White 7: 6500K
236 – 240
White 8: 7200K
241 – 245
White 9: 8000K
246 – 250
White 10: 8500K
251 – 255
White 11: 10000K
Strobe
000 – 010
No Function
011 – 255 0 – 20 Hz
Auto + Custom
000 – 010
No Function
011 – 020
Fans OFF (after 3 seconds)
021 – 030
Fans LOW (after 3 seconds)
031 – 040
Fans HIGH (after 3 seconds)
041 – 050
Fans NORMAL (after 3 seconds)
051 – 060
Fans AUTO (after 3 seconds)
061 – 070
Auto 1
071 – 080
Auto 2
081 – 090
Auto 3
091 – 100
Auto 4
101 – 110
Auto 5
111 – 120
Auto 6
121 – 130
Auto 7
131 – 140
Auto 8
141 – 150
Auto 9
151 – 160
Auto 10
161 – 170
Custom 1
171 – 180
Custom 2
181 – 190
Custom 3
191 – 200
Custom 4
201 – 210
Custom 5
211 – 220
Custom 6
221 – 230
Custom 7
231 – 240
Custom 8
241 – 250
Custom 9
251 – 255
Custom 10
Function
CH2 will control the STEP TIME, if CH9 is set to custom 01-10
CH3 will control the FADE TIME, if CH9 is set to custom 01-10
20
