AUTO
• Channel 9 selects the preset AUTO and CUSTOM programs (1-10).
• Channel 9 has priority over channels 2, 3, 4, 5, 6, 7 and 8.
• When activating the custom AUTO programs 1-10, it is possible to control the Step Time (CH2) and
Fade Time (CH3).
DIMMER SPEED
Enter DIM Mode (CH11) to select specific dimmer mode and dimmer speed. When DIMMER is set to OFF,
then RGBW and the MASTER DIMMER are linear. Dim 1/2/3/4 are speed modes of the non linear dimmer.
DIM1 is fastest, and DIM4 is slowest.
ID ADDRESS SELECTION
• CH12 is used to select the target ID address.
• Each independent DMX address may have up to 66 independent ID addresses.
• ID address "0" allows control of all fixtures simultaneously.
BLOCK SELECTION
CH13 allows the user to select a series of combinations of different colors and LED blocks
DMX Control BLOCK1
Channel Value
1 000 – 255
2 000 – 255
3 000 – 255
4 000 – 255
5 000 – 255
6 000 – 255
7 000 – 255
8 000 – 255
9 000 – 255
Function
Block 1 Red
0 – 100 %
Block 1 Green
0 – 100 %
Block 1 Blue
0 – 100 %
Block 2 Red
0 – 100 %
Block 2 Green
0 – 100 %
Block 2 Blue
0 – 100 %
Block 3 Red
0 – 100 %
Block 3 Green
0 – 100 %
Block 3 Blue
0 – 100 %
