- Page 1 Black Widow ORDERCODE 40213...
- Page 2 For more information: iwant@showtec.info You can get some of the best quality, best priced products on the market from Showtec. So next time, turn to Showtec for more great lighting equipment. Always get the best -- with Showtec ! Thank you!
-
Page 3: Table Of Contents
Showtec Showtec Black Widow Product Guide ™ Warning..…...................………………………………………….. Safety-instructions………………………………………………………………………………………….…. Operating Determinations……………………………………………………………………………………. Description..…................……….………………………………… Features……………………….………………………………………………………….………………….…. Installation................…...…………………………………….….. Installing the Lamp ............………………………………………..………… Set Up and Operation..............……..……………………………….… Maintenance...................………..………….…….……………… Changing the Lamp................…………………….………………… Replacing the Fuse................…………………….………………… Troubleshooting................………………….………………….….. Light........……………………………………...…………..……….……………...……. Product Specifications..............……………….…….………………….. -
Page 4: Warning
WARNING CAUTION! Keep this device away from rain and moisture! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! SAFETY INSTRUCTIONS Every person involved with the installation, operation and maintenance of this device has to: be qualified follow the instructions of this manual CAUTION! Be careful with your operations. -
Page 5: Operating Determinations
The arising condensation water might damage your device. Leave the device switched off until it has reached room temperature. If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely • (preferably in the original packing material), and return it to your Showtec dealer for service. -
Page 6: Connection With The Mains
Do not attempt the installation yourself ! Always let the installation be carried out by an authorized dealer ! Procedure: If the Black Widow is lowered from the ceiling or high joists, professional trussing systems have to be • used. -
Page 7: Description
Installation Installing the Lamp The Showtec Black Widow Strobe uses the PXA-50 (ordercode 80601) lightbulb as manufactured by all popular manufacturers. Use only the appropriate lamp for your unit. Note that, product versions that use other lamps, may be offered in the future. Check your product specification label for information. -
Page 8: Maintenance
Maintenance The Showtec Black Widow requires almost no maintenance. However, you should keep the unit clean. Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe protective shield clean with glass cleaner and a soft cloth. -
Page 9: Product Specifications
Product Specification Model: Showtec Black Widow Voltage : AC 230V-50Hz (CE) Speedcontrol: 1-15 flashes/sec. In- and output: 2 x 6,3 mm mono jack. Lamp included: PXA-50 50W (80601) Dimensions: 220x175x225mm (LxWxH) Weight: 0,225 kg Lamp Allowed lamp models*: Showtec PXA-50 50W ordercode 80601...
