SHOWTEC Spectral CYC2000 Product Manual page 23

10
11
Channel 12 (ID address selection)
000 – 009
010 – 019
020 – 029
030 – 039
040 – 049
050 – 059
060 – 069
070 – 079
080 – 089
090 – 099
100 – 109
110 – 119
120 – 129
130 – 139
140 – 149
150 – 159
160 – 169
170 – 179
180 – 189
190 – 199
200 – 209
210
211
13
MASTER DIMMER
• CH1 controls the intensity of the currently projected color.
• When the fader is at 255, the intensity of the output is at its maximum.
RED, GREEN, BLUE, WHITE & AMBER SELECTION
• Channels 2, 3, 4, 5 and 6 control the overall intensity of each respective color.
• Channels 2, 3, 4, 5 and 6 can be combined to create an unlimited range of colors.
COLOR MACROS & WHITE BALANCE
• Channel 7 selects the required COLOR MACRO and whites in different colors.
• Channel 7 has priority over channels 2, 3, 4, 5 and 6.
• Channel 1 is used to control the intensity of the COLOR MACRO.
STROBE
• CH8 is the strobe channel and controls the strobe effects of CH2, CH3, CH4, CH5 and CH6.
• The strobe is with an adjustable speed with a maximum of 20Hz.
000 – 255 Auto Speed.
CH10 will control the AutoSpeed, if CH9 is set to
(only if CH9 061-160)
Dimmer Speed.
000 – 009 Preset Dimmer Speed from Display Menu
010 – 029 Linear Dimmer
030 – 069 Non Linear Dimmer (fastest) 1
070 – 129 Non Linear Dimmer 2
130 – 189 Non Linear Dimmer 3
190 – 255 Non Linear Dimmer (slowest) 4
All ID‟s 212
ID 1 213
ID 2 214
ID 3 215
ID 4 216
ID 5 217
ID 6 218
ID 7 219
ID 8 220
ID 9 221
ID 10 222
ID 11 223
ID 12 224
ID 13 225
ID 14 226
ID 15 227
ID 16 228
ID 17 229
ID 18 230
ID 19 231
ID 20 232
ID 21 233
ID 22 234
Block Selections.
000 – 004 Block 1, Block 2, Block 3
005 – 034 Block 1
035 – 064 Block 2
065 – 094 Block 3
095 – 124 Block 1, Block 2
125 – 154 Block 2, Block 3
155 – 184 Block 1, Block 3
185 – 214 Block 1, Block 2, Block 3
215 – 255 No Function
ID 23 235
ID 24 236
ID 25 237
ID 26 238
ID 27 239
ID 28 240
ID 29 241
ID 30 242
ID 31 243
ID 32 244
ID 33 245
ID 34 246
ID 35 247
ID 36 248
ID 37 249
ID 38 250
ID 39 251
ID 40 252
ID 41 253
ID 42 254
ID 43 255
ID 44
ID 45
