Tray1 Paper Type Detting - Develop QC 2235 Plus Service Manual

QC 2235plus Theory of Operation Ver.1.0 Mar. 2004
12.3.6

Tray1 paper type detting

• Tray1 is an MPC that requires that the type of paper be set.
• Changing the position of the Paper Type Setting Dial selects different controls on the
machine side as detailed below.
System Speed
Paper Type
Plain paper, 2nd side
plain paper
Thick paper 1, 2nd
side thick paper 1
Thick paper 2, 2nd
side thick paper 2
Thick paper 3
2nd side thick paper 3
Envelopes
OHP transparencies
• Select thick paper 2 to use postcards.
• Select thick paper 1 to use labels.
Paper Type Board (PWB-S)
Paper Type Setting Dial
Heating Roller Set
(mm/s) Temperature (°C)
Monochrome
mode 190
165
Color/ACS
mode 180
100
185
60
190
170
(humidity during a
color print cycle
exceeds 60%)
2-57
Paper feed section
1st Image 2nd Image
Transfer Transfer
×
×
: Varies depending on the paper type
×: Not vary
4036ma2040c0
γ
Vg Vb
Table
×
×
